Mikrovlnný senzor pohybu pro montáž na strop, nebo na stěnu.

Microwave motion sensor surface mount
High-precision microwave motion sensor, LED ready

High-precision microwave motion sensor for indoor on-wall mounting.
LED and also for other illuminant but only with base load.
HF system 5,8 GHz, CW Radar, ISM band

protection class: 20 IP
lenght: 11,48 cm
width: 11,48 cm
height: 5,48 cm
input voltage: 230 V AC
height: 44 mm
diameter: 103 mm
protection: 2
Language of the manual: german/english
power source: 220 - 240 V AC
detection range: 360 °
luminous sensitivity adjustable: 3 - 2000 Lux
switching-off delay adjustable: 10 sec. - 12min.
switch contact: relay 300 W
switching capacity CFL: 300 W
switching capacity LED: 300 W
switching capacity filament bulb: 1200 W
installation height: 1.5 - 3.5 m
motions identification up to: 1 - 8 m
power consumption stand-by: 0,6 W
rated power: 1,4 W
minimum load: 1 W
color: white
